IDEAL Evomax 30 Product Guide

23
SYSTEM DESIGN OPTIONS
LOW HEIGHT FRAME & HEADER KITS
TOTAL OUTPUT
REQUIRED KW
NO. OF
BOILERS
HEADER
SIDE BY SIDE
FOOTPRINT SIZE
W X D (MM)
OPTIONAL LOW
LOSS HEADER
BOILER MODELS
FRAME/HEADER
PRODUCT NO.
30 1 DN50 550 x 642 209394 1 210012
40 1 DN50 550 x 642 209394 1 210012
60 1 DN50 550 x 642 209394 1 210012
80 1 DN50 550 x 642 209394 1 210012
100 1 DN50 550 x 642 209394 1 210012
120 1 DN50 550 x 642 209394 1 210012
150 1 DN50 550 x 666 209394 1 210012
60 2 DN65 1100 x 642 209395 2 x 30 210029
70 2 DN65 1100 x 642 209395 1 x 30 + 1 x 40 210029
80 2 DN65 1100 x 642 209395 2 x 40 210029
90 2 DN65 1100 x 642 209395 1 x 60 + 1 x 30 210029
100 2 DN65 1100 x 642 209395 1 x 60 + 1 x 40 210029
110 2 DN65 1100 x 642 209395 1 x 80 + 1 x 30 210029
120 2 DN65 1100 x 642 209395 2 x 60 210029
130 2 DN65 1100 x 642 209395 1 x 100 + 1 x 30 210029
140 2 DN65 1100 x 642 209395 1 x 80 + 1 x 60 210029
140 2 DN65 1100 x 642 209395 1 x 100 + 1 x 40 210029
150 2 DN65 1100 x 642 209395 1 x 120 + 1 x 30 210029
160 2 DN65 1100 x 642 209395 2 x 80 210029
160 2 DN65 1100 x 642 209395 1 x 100 + 1 x 60 210029
180 2 DN65 1100 x 642 209395 1 x 100 + 1 x 80 210029
180 2 DN65 1100 x 642 209395 1 x 120 + 1 x 60 210029
180 2 DN65 1100 x 666 209395 1 x 150 + 1 x 30 210029
190 2 DN65 1100 x 666 209395 1 x 150 + 1 x 40 210029
200 2 DN65 1100 x 642 209395 2 x 100 210029
200 2 DN65 1100 x 642 209395 1 x 120 + 1 x 80 210029
210 2 DN65 1100 x 666 209395 1 x 150 + 1 x 60 210029
220 2 DN65 1100 x 642 209395 1 x 120 + 1 x 100 210029
230 2 DN65 1100 x 666 209395 1 x 150 + 1 x 80 210029
240 2 DN65 1100 x 642 209395 2 x 120 210029
250 2 DN65 1100 x 666 209395 1 x 150 + 1 x 100 210029
270 2 DN65 1100 x 666 209395 1 x 150 + 1 x 120 210029
300 2 DN65 1100 x 666 209395 2 x 150 210029
90 3 DN80 1650 x 642 252437 3 x 30 210020
100 3 DN80 1650 x 642 252437 1 x 40 + 2 x 30 210020
110 3 DN80 1650 x 642 252437 2 x 40 + 1 x 30 210020
120 3 DN80 1650 x 642 252437 3 x 40 210020
120 3 DN80 1650 x 642 252437 1 x 60 + 2 x 30 210020
130 3 DN80 1650 x 642 252437 1 x 60 + 1 x 40 + 1 x 30 210020
140 3 DN80 1650 x 642 252437 1 x 60 + 2 x 40 210020
150 3 DN80 1650 x 642 252437 2 x 60 + 1 x 30 210020
160 3 DN80 1650 x 642 252437 1 x 80 + 2 x 40 210020
170 3 DN80 1650 x 642 252437 1 x 80 + 1 x 60 + 1 x 30 210020
180 3 DN80 1650 x 642 252437 3 x 60 210020
180 3 DN80 1650 x 642 252437 1 x 100 + 2 x 40 210020
190 3 DN80 1650 x 642 252437 2 x 80 + 1 x 30 210020
200 3 DN80 1650 x 642 252437 2 x 80 + 1 x 40 210020
220 3 DN80 1650 x 642 252437 2 x 80 + 1 x 60 210020
