IDEAL SecuriTest IP User Manual

171810.01 SecuriTEST® IP 25
SecuriTEST® IP User Manual
ANALOG CAMERA TEST - CVBS
Cameras using the Composite Video Blanking and Sync (CVBS) analog standard can be
tested
Settings for Photo or Video file naming. Auto creates a file name
automatically. Manual allows user to set file name.
Touch +/- or drag the sliders to adjust the picture settings
Displays the video stream from the connected camera
Touch to display the Video Levels on the bottom left
corner. Displays the levels of the different
components of the Composite Video stream from
the connected camera
as shown on the right.
12VDC
