IDEC MICROSmart FC6A Series User Manual

2: P RODUCT S PECIFICATIONS
2-74 FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722
Terminal Arrangement and Wiring Examples
■ FC6A-N08B1, FC6A-N08B4
The 3 COM lines are connected in the module.
For wiring precautions, see "Input/Output Wiring" on page 3-18.
DC Sink Input Wiring Example
DC Source Input Wiring Example
*1 24V DC for products with a version number lower than V400. For details on the version number of modules, see "Checking the Version Number"
on page 2-1.
Screw fastened type: FC6A-N08B1 Push-in type: FC6A-N08B4
Applicable connector: FC6A-PMTB11PN02 Applicable connector: FC6A-PMSB11PN02
DC.IN
0
4
5
6
7
1
2
3
FC6A-N08B1
COM COM COM 7 6 5 4 3 2 1 0
DC.IN
0
4
5
6
7
1
2
3
FC6A-N08B4
COM COM COM 7 6 5 4 3 2 1 0
1
0 I0
I1
I2
I3
I4
I5
I6
I7
COM
2
3
4
5
6
7
COM
COM
COM
COM
COM
Terminal No. I/O
+ -
-
+
PNP
12/24V DC
*1
2-wire
Sensor
1
0 I0
I1
I2
I3
I4
I5
I6
I7
COM
2
3
4
5
6
7
COM
COM
COM
COM
COM
Terminal No. I/O
- +
+
-
12/24V DC
*1
2-wire
Sensor
NPN
