2: P RODUCT S PECIFICATIONS
2-186 FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722
Rating at Max Surrounding Air Temperature of 55°C/65°C
The input/output ratings at Max Surrounding Air Temperature of 55°C/65°C are as follows.
Model Names Type Air Temp Inputs Outputs
All-in-One CPU
module
FC6A-C16R1AE
55°C
9 inputs: 24V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 7 mA/PT
7 relay outputs:
240V AC / 30V DC, 2 A (GEN/RES) 7 A (Common)
65°C
9 inputs: 24V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 7 mA/PT
Tota l Max. 28 mA, 4 PTs
7 relay outputs:
240V AC / 30V DC, 2 A (GEN/RES) 7 A (Common)
Total Max. 6 A, 3 PTs
FC6A-C16R1CE
55°C
9 inputs: 24V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 7 mA/PT
7 relay outputs:
240V AC / 30V DC, 2 A (GEN/RES) 7 A (Common)
65°C
9 inputs: 24V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 7 mA/PT
Tota l Max. 28 mA, 4 PTs
7 relay outputs:
240V AC / 30V DC, 2 A (GEN/RES) 7 A (Common)
Total Max. 6 A, 3 PTs
FC6A-C16P1CE
55°C
9 inputs: 24V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 7 mA/PT
7 transistor source outputs:
24V DC, 0.5 A/PT
Class 2
65°C
9 inputs: 24V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 7 mA/PT
Tota l Max. 17 mA, 3 PTs
7 transistor source outputs:
24V DC, 0.5 A/PT
Class 2
Total Max. 1 A, 2 PTs
FC6A-C16K1CE
55°C
9 inputs: 24V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 7 mA/PT
7 transistor sink outputs:
24V DC, 0.5 A/PT
65°C
9 inputs: 24V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 7 mA/PT
Tota l Max. 17 mA, 3 PTs
7 transistor sink outputs:
24V DC, 0.5 A/PT
Total Max. 1 A, 2 PTs
FC6A-C16R1DE
55°C
9 inputs: 12V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 6 mA/PT
7 relay outputs:
240V AC / 30V DC, 2 A (GEN/RES) 7 A (Common)
65°C
9 inputs: 12V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 6 mA/PT
Tota l Max. 24 mA, 4 PTs
7 relay outputs:
240V AC / 30V DC, 2 A (GEN/RES) 7 A (Common)
Total Max. 6 A, 3 PTs
FC6A-C16P1DE
55°C
9 inputs: 12V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 6 mA/PT
7 transistor source outputs:
12 V DC, 0.5 A/PT resistive
Limited energy
65°C
9 inputs: 12V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 6 mA/PT
Tota l Max. 18 mA, 3 PTs
7 transistor source outputs:
12 V DC, 0.5 A/PT resistive
Total Max. 1A, 2 PTs
Limited energy
FC6A-C16K1DE
55°C
9 inputs: 12V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 6 mA/PT
7 transistor sink outputs:
12 V DC, 0.5 A/PT resistive
Limited energy
65°C
9 inputs: 12V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 6 mA/PT
Tota l Max. 18 mA, 3 PTs
7 transistor sink outputs:
12 V DC, 0.5 A/PT resistive
Total Max. 1A, 2 PTs
Limited energy
FC6A-C24R1AE
55°C
14 inputs: 24V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 7 mA/PT
10 relay outputs:
240V AC / 30V DC, 2 A (GEN/RES) 7 A (Common)
65°C
14 inputs: 24V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 7 mA/PT
Tota l Max. 45 mA, 7 PTs
10 relay outputs:
240V AC / 30V DC, 2 A (GEN/RES) 7 A (Common)
Total Max. 10 A, 5 PTs
FC6A-C24R1CE
55°C
14 inputs: 24V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 7 mA/PT
10 relay outputs:
240V AC / 30V DC, 2 A (GEN/RES) 7 A (Common)
65°C
14 inputs: 24V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 7 mA/PT
Tota l Max. 45 mA, 7 PTs
10 relay outputs:
240V AC / 30V DC, 2 A (GEN/RES) 7 A (Common)
Total Max. 10 A, 5 PTs
