7: HMI F UNCTION
Reading and Writing Recipe Files
This section describes how to write recipe files to the SD memory card and how to read recipe files from the SD memory card.
Writing Recipe Files (SD memory card –> CPU module)
1. On the standard screen, press the (ESC) + (OK) buttons.
The system menu is displayed.
2. Select External Memory with the (up) and (down) buttons and press the (OK) button.
3. Select SD Card with the (up) and (down) buttons and press the (OK) button.
4. Select Recipe with the (up) and (down) buttons and press the (OK) button.
5. Select Write Recipe with the (up) and (down) buttons and press the (OK) button.
6. Select Block Number with the (up) and (down) buttons and press the (OK) button.
7. While the recipe is being written, the screen below is displayed. When finished, the screen in step 5 is displayed.
Stopped
2015/DEC/01/TUE
13:30:40
Run
Edit Program
External Memory
Configurations
SD Card
Stop Access
Format
Recipe
Program
Write Recipe
Read Recipe
Write Recipe
(SD
-
>PLC)
Block Number:
1
