FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722 8-3
8: I NSTRUCTIONS R EFERENCE
Advanced Instruction List
Group Symbol Name
Valid Data Type See Page
(Ladder
Programming
Manual)
WI D L F
NOP NOP No Operation
3: Instructions
Reference
Move
MOV Move XXXXX
5: Move
Instructions
MOVN Move Not X X X X
IMOV Indirect Move X X X
IMOVN Indirect Move Not X X
MOVC Move Characters
BMOV Block Move X
IBMV Indirect Bit Move X
IBMVN Indirect Bit Move Not X
NSET N Data Set X X X X X
NRS N Data Repeat Set XXXXX
XCHG Exchange X X
TCCST Timer/Counter Current Value Store X X
Data Comparison
CMP= Compare Equal To XXXXX
6: Data
Comparison
Instructions
CMP<> Compare Unequal To XXXXX
CMP< Compare Less Than XXXXX
CMP> Compare Greater Than XXXXX
CMP<= Compare Less Than or Equal To XXXXX
CMP>= Compare Greater Than or Equal To XXXXX
ICMP>= Interval Compare Greater Than or Equal ToXXXXX
LC= Load Compare Equal To XXXXX
LC<> Load Compare Unequal To XXXXX
LC< Load Compare Less Than XXXXX
LC> Load Compare Greater Than XXXXX
LC<= Load Compare Less Than or Equal To XXXXX
LC>= Load Compare Greater Than or Equal To XXXXX
Binary Arithmetic
ADD Addition XXXXX
7: Binary
Arithmetic
Instructions
SUB Subtraction XXXXX
MUL Multiplication X X X X X
DIV Division X X X X X
INC Increment X X X X
DEC Decrement XXXX
ROOT Root X X X
SUM
Sum (ADD) XXXXX
Sum (XOR) X
RNDM
Random X
Boolean Computation
ANDW AND Word X X
8: Boolean
Computation
Instructions
ORW OR Word X X
XORW Exclusive OR Word X X
Shift and Rotate
SFTL Shift Left
9: Shift / Rotate
Instructions
SFTR Shift Right
BCDLS BCD Left Shift X
WSFT Word Shift X
ROTL Rotate Left X X
ROTR Rotate Right X X
