IDEC MICROSmart FC6A Series User Manual

FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722 2-77
2: P RODUCT S PECIFICATIONS
■ FC6A-N16B3
*1 24V DC for products with a version number lower than V400. For details on the version number of modules, see "Checking the Version Number"
on page 2-1.
Connector type Applicable connector: FC4A-PMC20PNO2
The two COM lines are each connected in the module.
For wiring precautions, see "Input/Output Wiring" on page 3-18. For the connector cable, see
"Cables" on page A-14.
DC Sink Input Wiring Example
DC Source Input Wiring Example
DC.IN
0
1
2
3
4
5
6
7
10
11
12
13
14
15
16
17
FC6A-N16B3
20 19
2 1
18
20 I0
I1
I2
I3
I4
I5
I6
I7
COM
16
14
12
10
8
6
4
2
NC
17
19 I10
I11
I12
I13
I14
I15
I16
I17
COM
15
13
11
9
7
5
3
1
NC
Terminal No. I/O Terminal No. I/O
+ -
-
+
-
+
PNP PNP
- +
2-wire
Sensor
12/24V DC
*1
12/24V DC
*1
2-wire
Sensor
18
20 I0
I1
I2
I3
I4
I5
I6
I7
COM
16
14
12
10
8
6
4
2
NC
17
19 I10
I11
I12
I13
I14
I15
I16
I17
COM
15
13
11
9
7
5
3
1
NC
Terminal No. I/O Terminal No. I/O
- +
+
-
NPN
+
-
NPN
+ -
2-wire
Sensor
12/24V DC
*1
12/24V DC
*1
2-wire
Sensor
