FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722 2-79
2: P RODUCT S PECIFICATIONS
■ FC6A-N08A11, FC6A-N08A14
Each of the terminals for COM0 and COM1 are independent.
For wiring precautions, see "Input/Output Wiring" on page 3-18.
AC input wiring example
Screw fastened type: FC6A-N08A11
Applicable connector: FC6A-PMTB11PN02
Push-in type: FC6A-N08A14
Applicable connector: FC6A-PMSB11PN02
Ry.OUT
0
4
5
6
7
1
2
3
COM1 7 6 5 4 NC COM0 3 2 1 0
FC6A-R081
AC.IN
0
4
5
6
7
1
2
3
COM1 7 6 5 4 NC COM0 3 2 1 0
FC6A-N08A14
1
0 I0
I1
I2
I3
COM0
NC
I4
I5
I6
2
3
COM0
NC
4
5
6
7
I7
COM1
COM1
Terminal No. I/O
Do not connect an external load.
Caution
