IDEC MICROSmart FC6A Series User Manual

2: P RODUCT S PECIFICATIONS
2-90 FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722
■ FC6A-T08K1, FC6A-T08K4
For wiring precautions, see "Input/Output Wiring" on page 3-18.
Insert a fuse that corresponds to the load.
*1 24V DC for products with a version number lower than V400. For details on the version number of modules, see "Checking the Version Number"
on page 2-1.
Screw fastened type: FC6A-T08K1 Push-in type: FC6A-T08K4
Applicable connector: FC6A-PMTB11PN02 Applicable connector: FC6A-PMSB11PN02
Tr.OUT
0
4
5
6
7
1
2
3
FC6A-T08K1
+V
COM(-) COM(-)
76543210
Tr.OUT
0
4
5
6
7
1
2
3
FC6A-T08K4
+V
COM(-) COM(-)
76543210
: Fuse : Load
L
1
0 Q0
Q1
Q2
Q3
COM(-)
Q4
Q5
Q6
2
3
COM(-)
+V
+V
4
5
6
7
Q7
Terminal No. I/O
COM(-)
COM(-)
L
L
L
L
L
L
L
L
- +
12/24V DC
*1
