FC6A S
ERIES
MICROS
MART
U
SER
’
S
M
ANUAL
FC9Y-B1722 2-103
2: P
RODUCT
S
PECIFICATIONS
■ FC6A-M24BR1, FC6A-M24BR4
The 3 COM lines are connected in the module.
For wiring precautions, see "Input/Output Wiring" on page 3-18.
DC Sink Input Wiring Example
*1 24V DC for products with a version number lower than V400. For details on the version number of modules, see "Checking the Version Number"
on page 2-1.
Screw fastened type: FC6A-M24BR1 Push-in type: FC6A-M24BR4
Applicable connector: FC6A-PMTC17PN02
FC6A-PMTC11PN02
Applicable connector: FC6A-PMSC17PN02
FC6A-PMSC11PN02
DC.IN
Ry.OUT
1
2
3
4
5
6
7
10
11
12
13
14
15
16
17
0
1
2
3
4
5
6
7
0
TB1
TB2
FC6A-M24BR1
COM0 17 16 15 14 13 12 11 10 7 6 5 4 3 2 1 0
COM2 7 6 5 4 NC COM1 3 2 1 0
DC.IN
Ry.OUT
1
2
3
4
5
6
7
10
11
12
13
14
15
16
17
0
1
2
3
4
5
6
7
0
TB1
TB2
FC6A-M24BR4
COM0 17 16 15 14 13 12 11 10 7 6 5 4 3 2 1 0
COM2 7 6 5 4 NC COM1 3 2 1 0
1
0 I0
I1
I2
I3
I4
I5
I6
I7
2
3
4
5
6
7
11
10 I10
I11
I12
I13
I14
I15
I16
I17
COM
12
13
14
15
16
17
COM
Terminal No.
I/O
+
-
-
+
PNP
12/24V DC
*1
2-wire
Sensor
To Next Page
