IDEC MICROSmart FC6A Series User Manual

2: P RODUCT S PECIFICATIONS
2-106 FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722
Model List
Module Type I/O Points I/O Signal
Cable Terminal
Type 1
Cable Terminal
Type 2
Type No.
Analog input
module
Input
2
Voltage input (0 to 10 V, -10 to +10 V)
Current input (4 to 20 mA, 0 to 20 mA)
Termi n a l block type
(5.08 mm pitch)
Screw fastened type FC6A-J2C1
Push-in type FC6A-J2C4
4
Voltage input (0 to 10 V, -10 to +10 V)
Current input (4 to 20 mA, 0 to 20 mA)
Termi n a l block type
(3.81 mm pitch)
Screw fastened type FC6A-J4A1
Push-in type FC6A-J4A4
8
Voltage input (0 to 10 V, -10 to +10 V)
Current input (4 to 20 mA, 0 to 20 mA)
Termi n a l block type
(3.81 mm pitch)
Screw fastened type FC6A-J8A1
Push-in type FC6A-J8A4
4
Voltage input (0 to 10 V, -10 to +10 V)
Current input (4 to 20 mA, 0 to 20 mA)
Thermocouple (K, J, R, S, B, E, T, N, C)
Resistance thermometer (Pt100, Pt1000,
Ni100, Ni1000)
Termi n a l block type
(3.81 mm pitch)
Screw fastened type FC6A-J4CN1
Push-in type FC6A-J4CN4
4 Thermocouple (K, J, R, S, B, E, T, N, C)
Termi n a l block type
(3.81 mm pitch)
Screw fastened type FC6A-J4CH1Y
Push-in type FC6A-J4CH4Y
8
Thermocouple (K, J, R, S, B, E, T, N, C)
Thermistor (PTC, NTC)
Resistance (100 to 32,000 Ω)
Termi n a l block type
(3.81 mm pitch)
Screw fastened type FC6A-J8CU1
Push-in type FC6A-J8CU4
Analog output
module
Output
2
Voltage output (0 to 10 V, -10 to +10 V)
Current output (4 to 20 mA, 0 to 20 mA)
Termi n a l block type
(5.08 mm pitch)
Screw fastened type FC6A-K2A1
Push-in type FC6A-K2A4
4
Voltage output (0 to 10 V, -10 to +10 V)
Current output (4 to 20 mA, 0 to 20 mA)
Termi n a l block type
(5.08 mm pitch)
Screw fastened type FC6A-K4A1
Push-in type FC6A-K4A4
Mixed analog
I/O module
I/O
2 (Input)
Voltage input (0 to 10 V, -10 to +10 V)
Current input (4 to 20 mA, 0 to 20 mA)
Thermocouple (K, J, R, S, B, E, T, N, C)
Resistance thermometer (Pt100, Pt1000,
Ni100, Ni1000)
Termi n a l block type
(5.08 mm pitch)
Screw fastened type FC6A-L03CN1
Push-in type FC6A-L03CN4
1 (Output)
Voltage output (0 to 10 V, -10 to +10 V)
Current output (4 to 20 mA, 0 to 20 mA)
I/O
4 (Input)
Voltage input (0 to 10 V, -10 to +10 V)
Current input (4 to 20 mA, 0 to 20 mA)
Termi n a l block type
(3.81 mm pitch)
Screw fastened type FC6A-L06A1
2 (Output)
Voltage output (0 to 10 V, -10 to +10 V)
Current output (4 to 20 mA, 0 to 20 mA)
Push-in type FC6A-L06A4
