FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722 1-3
1: G ENERAL I NFORMATION
Analog I/O module
PID module
Communication module
FC6A -
J4CN1
Input type
None: Voltage/current input
N: Voltage/current/resistance thermometer input
U: Thermistor/thermocouple input
H: Thermocouple input
Maximum resolution
A: 12 bits
C: 16 bits
Terminal specification
1: Removableterminal block (Screw)
4: Removable terminal block (Push-in)
Isolation
Y: Isolated between channels
None: No isolation
I/O points
2: 2 I/O points
4: 4 I/O points
8: 8 I/O points
03: 3 I/O points
06: 6 I/O points
Module type
J: Analog input module
K: Analog output module
L: Mixed analog I/O module
FC6A -
F2MR1
Output type
None: Voltage/current output
R: Relay output
Input type
M: Multi input
Terminal specification
1: Removable terminal block (Screw)
4: Removable terminal block (Push-in)
Control loop points
2: 2 points
Module type
F: PID module
FC6A -
SIF 5 2
Communication specification
5: RS-232C or RS-485 selectable
Number of ports
2: 2 ports
Module type
SIF: Serial communication module
Terminal specification
1: Removable terminal block (Screw)
4: Removable terminal block (Push-in)
