CAN J1939 All-
in-One CPU
module
FC6A-C40R1AEJ
55°C
24 inputs: 24V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 7 mA/PT
16 relay outputs:
240V AC / 30V DC, 2 A (GEN/RES) 7 A (Common)
65°C
24 inputs: 24V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 7 mA/PT
Total Max. 80 mA, 12 PTs
16 relay outputs:
240V AC / 30V DC, 2 A (GEN/RES) 7 A (Common)
Total Max. 16 A, 8 PTs
FC6A-C40R1CEJ
55°C
24 inputs: 24V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 7 mA/PT
16 relay outputs:
240V AC / 30V DC, 2 A (GEN/RES) 7 A (Common)
65°C
24 inputs: 24V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 7 mA/PT
Total Max. 80 mA, 12 PTs
16 relay outputs:
240V AC / 30V DC, 2 A (GEN/RES) 7 A (Common)
Total Max. 16 A, 8 PTs
FC6A-C40P1CEJ
55°C
24 inputs: 24V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 7 mA/PT
16 transistor source outputs:
24V DC, 0.5 A/PT
Class 2
65°C
24 inputs: 24V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 7 mA/PT
Tota l Max. 48 mA, 8 PTs
16 transistor source outputs:
24V DC, 0.5 A/PT
Class 2
Total Max. 3 A, 6 PTs
FC6A-C40K1CEJ
55°C
24 inputs: 24V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 7 mA/PT
16 transistor sink outputs:
24V DC, 0.5 A/PT
65°C
24 inputs: 24V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 7 mA/PT
Tota l Max. 48 mA, 8 PTs
16 transistor sink outputs:
24V DC, 0.5 A/PT
Total Max. 3 A, 6 PTs
FC6A-C40R1DEJ
55°C
24 inputs: 12V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 6 mA/PT
16 relay outputs:
240V AC / 30V DC, 2 A (GEN/RES) 7 A (Common)
65°C
24 inputs: 12V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 6 mA/PT
Total Max. 70 mA, 12 PTs
16 relay outputs:
240V AC / 30V DC, 2 A (GEN/RES) 7 A (Common)
Total Max. 16 A, 8 PTs
FC6A-C40P1DEJ
55°C
24 inputs: 12V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 6 mA/PT
16 transistor source outputs:
12V DC, 0.5 A/PT
Class 2
65°C
24 inputs: 12V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 6 mA/PT
Tota l Max. 42 mA, 8 PTs
16 transistor source outputs:
12V DC, 0.5 A/PT
Class 2
Total Max. 3 A, 6 PTs
FC6A-C40K1DEJ
55°C
24 inputs: 12V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 6 mA/PT
16 transistor sink outputs:
12V DC, 0.5 A/PT
65°C
24 inputs: 12V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 6 mA/PT
Tota l Max. 42 mA, 8 PTs
16 transistor sink outputs:
12V DC, 0.5 A/PT
Total Max. 3 A, 6 PTs
Plus CPU module
FC6A-D16R1CEE
55°C
8 inputs: 24V DC,
Input 0, 1, 3, 4, 6, 7: 5 mA/PT
Others: 7 mA/PT
8 relay outputs:
240V AC /30V DC, 2 A (GEN/RES) 7 A (Common);
D300, 2 A 30V AC, 180 VA 120/240V AC, R300, 1 A
30V DC, 28 VA 125/250V DC pilot duty
65°C
8 inputs: 24V DC,
Input 0, 1, 3, 4, 6, 7: 5 mA/PT
Others: 7 mA/PT
Tota l Max. 22 mA, 4 PTs
8 relay outputs:
240V AC /30V DC, 2 A (GEN/RES) 7 A (Common);
D300, 2 A 30V AC, 180 VA 120/240V AC, R300, 1 A
30V DC, 28 VA 125/250V DC pilot duty
Total Max. 8 A, 4 PTs
FC6A-D16R4CEE
55°C
8 inputs: 24V DC,
Input 0, 1, 3, 4, 6, 7: 5 mA/PT
Others: 7 mA/PT
8 relay outputs:
240V AC /30V DC, 2 A (GEN/RES) 7 A (Common);
D300, 2 A 30V AC, 180 VA 120/240V AC, R300, 1 A
30V DC, 28 VA 125/250V DC pilot duty
65°C
8 inputs: 24V DC,
Input 0, 1, 3, 4, 6, 7: 5 mA/PT
Others: 7 mA/PT
Tota l Max. 22 mA, 4 PTs
8 relay outputs:
240V AC /30V DC, 2 A (GEN/RES) 7 A (Common);
D300, 2 A 30V AC, 180 VA 120/240V AC, R300, 1 A
30V DC, 28 VA 125/250V DC pilot duty
Total Max. 8 A, 4 PTs
Model Names Type Air Temp Inputs Outputs
