IDEC MICROSmart FC6A Series User Manual

3: I NSTALLATION AND W IRING
3-46 FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722
Recommended Ferrule List
The following ferrules can be used with the FC6A Series MICROSmart.
The recommended ferrules are manufactured by Phoenix Contact (top) or Weidmüller (bottom).
■ All-in-One CPU module/CAN J1939 All-in-One CPU module
CPU Module Terminals
Power Supply
Terminals
Input Terminals
Output Terminals
CAN Port
(CAN J1939 All-in-One
CPU module only)
Wire Type
UL1007
UL2464
Equivalent
UL1015
Equivalent
UL1007
UL2464
Equivalent
UL1015
Equivalent
UL1007
UL2464
Equivalent
*1
UL1015
Equivalent
*1
Stripping length (mm) 7 7 10
Wire thickness (mm
2
) 0.2 to 2.5 0.2 to 2.5 0.2 to 2.5
Wire
gauge
AWG 24
1-wire
usage
AI 0,25- 6 (3203040)
H0,25/10 HBL (9025740000)
Yes ― Yes ―― ―
AI 0,25- 8 (3203037)
H0,25/12T GE (9021020000)
Yes ― Yes ―― ―
AI 0,25-10 (3241128)
―
――――Yes ―
AWG22
1-wire
usage
AI 0,34- 6 (3203053)
H0,34/10 TK (9025750000)
Yes ― Yes ―― ―
AI 0,34- 8 (3203066)
H0,34/12 TK (9025770000)
Yes ― Yes ―― ―
AI 0,34-10 (3241129)
―
――――Yes ―
AWG20
1-wire
usage
AI 0,5- 6 (3200687)
H0,5/12D W (9019000000)
Yes ― Yes ―― ―
AI 0,5- 8 (3200014)
H0,5/14D W (9019010000)
Yes ― Yes ―― ―
AI 0,5- 8 GB (1208966)
―
― Yes ― Yes ――
AI 0,5-10 (3201275)
H0,5/16D W (9019020000)
――――Yes ―
AI 0,5-10 GB (3203150)
H0,5/16 DS W (9202910000)
―――― ―Yes
2-wire
usage
AI-TWIN 2 x 0,5-8 (3200933)
H0,5/14D ZH W (9037380000)
Yes ― Yes ―― ―
AI-TWIN 2 x 0,5-10 (3203309)
H0,5/16D ZH W (9037390000)
――――Yes ―
AWG18
1-wire
usage
AI 0,75- 6 (3200690)
H0,75/12D GR (9019030000)
Yes ― Yes ―― ―
AI 0,75- 8 (3200519)
H0,75/14D GR (9019040000)
Yes ― Yes ―― ―
AI 0,75-10 (3201288)
H0,75/16D GR (9019050000)
――――Yes ―
AI 1-8 (3200030)
H1,0/14D R (9019080000)
― Yes ― Yes ――
AI 1-10 (3200182)
H1,0/16D R (9019100000)
―――― ―Yes
2-wire
usage
AI-TWIN 2 x 0,75-8 (3200807)
H0,75/14D ZH GR (9037410000)
Yes ― Yes ―― ―
AI-TWIN 2 x 0,75-10 (3200975)
H0,75/16D ZH GR (9037420000)
――――Yes ―
AWG16
1-wire
usage
AI 1,5- 6 (3200755)
―
Yes Yes Yes Yes ――
AI 1,5- 8 (3200043)
H1,5/14D SW (9019120000)
Yes Yes Yes Yes ――
AI 1,5-10 (3200195)
H1,5/16D SW (9019130000)
――――Yes Yes
2-wire
usage
AI-TWIN 2 x 1,5-8 (3200823)
H1,5/16D ZH SW (9037470000)
Yes Yes Yes Yes ――
