IDEC MICROSmart FC6A Series

5: F UNCTIONS AND S ETTINGS
5-6 FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722
All-in-One CPU module
Plus CPU module
Type 16-I/O type 24-I/O type 40-I/O type
External Input I0 to I7, I10 I0 to I7, I10 to I15 I0 to I7, I10 to I17, I20 to I27
Type Plus 16-I/O type Plus 32-I/O type
External Input I0 to I7 I0 to I7, I10 to I17
