FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722 6-19
6: D EVICES
D8107 to
D8119
— Reserved — ――
D8120
HMI Module Information
Type ID/Statu s ― R
D8121 System Software Version ― R
D8122
Cartridge Slot 1 Information
Type ID/Statu s ― R
D8123 System Software Version ― R
D8124
Cartridge Slot 2 Information
Type ID/Statu s ― R
D8125 System Software Version ― R
D8126
Cartridge Slot 3 Information
Type ID/Statu s ― R
D8127 System Software Version ― R
D8128 to
D8169
— Reserved — ――
D8170 Analog I/O Cartridge I/O AI2/AQ2 Every scan R
D8171 Analog I/O Cartridge I/O AI3/AQ3 Every scan R
D8172 Analog I/O Cartridge Status AI2/AQ2 Every scan R
D8173 Analog I/O Cartridge Status AI3/AQ3 Every scan R
D8174 Analog I/O Cartridge I/O AI4/AQ4 Every scan R
D8175 Analog I/O Cartridge I/O AI5/AQ5 Every scan R
D8176 Analog I/O Cartridge Status AI4/AQ4 Every scan R
D8177 Analog I/O Cartridge Status AI5/AQ5 Every scan R
D8178 Analog I/O Cartridge I/O AI6/AQ6 Every scan R
D8179 Analog I/O Cartridge I/O AI7/AQ7 Every scan R
D8180 Analog I/O Cartridge Status AI6/AQ6 Every scan R
D8181 Analog I/O Cartridge Status AI7/AQ7 Every scan R
D8182 to
D8191
— Reserved — ――
D8192
High-speed
Counter
(Group 2/I1)
High Word
Current Value/Frequency Measurement (I1) Current
Value
Every scan R
D8193 Low Word Every scan R
D8194 High Word
Preset Value
― R/W
D8195 Low Word ― R/W
D8196 High Word
Reset Value
― R/W
D8197 Low Word ― R/W
D8198
High-speed
Counter
(Group 6/I7)
High Word
Current Value/Frequency Measurement (I7) Current
Value
Every scan R
D8199 Low Word Every scan R
D8200 High Word
Preset Value
― R/W
D8201 Low Word ― R/W
D8202 High Word
Reset Value
― R/W
D8203 Low Word ― R/W
D8204 Control Signal Status (Port 6 to 9) Every scan R
D8205 RS232C DSR Input Control Signal Option (Port 6 to 9) Every scan R/W
D8206 RS232C DTR Output Control Signal Option (Port 6 to 9) Every scan R/W
D8207 to
D8209
— Reserved — ――
D8210
High-speed
Counter
(Group 1/I0)
High Word
Current Value/Frequency Measurement (I0) Current
Value
Every scan R
D8211 Low Word Every scan R
D8212 High Word
Preset Value
― R/W
D8213 Low Word ― R/W
D8214 Interrupt Input Jump Destination Label No. (I7) ― R/W
D8215 Interrupt Input Jump Destination Label No. (I0) ― R/W
D8216
High-speed
Counter
(Group 1/I0)
High Word
Reset Value
― R/W
D8217 Low Word ― R/W
D8218
High-speed
Counter
(Group 3/I3)
High Word
Current Value/Frequency Measurement (I3) Current
Value
Every scan R
D8219 Low Word Every scan R
D8220 High Word
Preset Value
― R/W
D8221 Low Word ― R/W
Device
Address
Description Update Timing R/W
