FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722 7-33
7: HMI F UNCTION
Modifying Device Values
This section describes how to specify a device and modify that device value.
Modifying a Bit Device Value
This section describes an example of switching on M0012 while the user program is running.
1. On the standard screen, press the (ESC) + (OK) buttons.
The system menu is displayed.
2. Select Device Monitor with the (up) and (down) buttons and press the (OK) button.
The FC6A Series MICROSmart switches to the Device Monitor mode.
3. Select device type: M (internal relay) with the (left) and (right) buttons and press and hold the (OK) button.
0 flashes to indicate the focus is on M0000.
4. With the (up) and (down) buttons, select M0010.
0 flashes to indicate the focus is on M0010.
5. Move the cursor to 2 with the (right) button and press the (OK) button.
M0012 turns on.
Running
13:30:40
2015/DEC/01/TUE
Stop
External Memory
Device Monitor
Status Monitor
M01234567
M 01234567
M01234567
M 012345
00000
,
00010
,
00020
,
00030
,
M01234567
M 01234567
M01234567
M 012345
00000
,
00010
,
00020
,
00030
,
M01234567
M01234567
M01234567
M 012345
00000
,
00010
,
00020
,
00030
,
