2: P RODUCT S PECIFICATIONS
2-12 FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722
■ 24V DC Power Type
Type No.
FC6A-C16R1CE, FC6A-C16R4CE, FC6A-C16K1CE, FC6A-C16K4CE, FC6A-C16P1CE,
FC6A-C16P4CE, FC6A-C24R1CE, FC6A-C24R4CE, FC6A-C24K1CE, FC6A-C24K4CE,
FC6A-C24P1CE, FC6A-C24P4CE, FC6A-C40R1CE, FC6A-C40R4CE, FC6A-C40K1CE,
FC6A-C40K4CE, FC6A-C40P1CE, FC6A-C40P4CE, FC6A-C40R1CEJ, FC6A-C40R4CEJ,
FC6A-C40K1CEJ, FC6A-C40K4CEJ, FC6A-C40P1CEJ, FC6A-C40P4CEJ
Rated Power Voltage 24V DC
Voltage Fluctuation Range 20.4 to 28.8V DC (including ripple)
Maximum Power Consumption Standalone When Maximum Load is Connected
FC6A-C16R1CE 3.36 W (24V DC) 13.44 W (24V DC)
FC6A-C16R4CE 3.36 W (24V DC) 13.44 W (24V DC)
FC6A-C16K1CE 4.56 W (24V DC) 13.44 W (24V DC)
FC6A-C16K4CE 4.56 W (24V DC) 13.44 W (24V DC)
FC6A-C16P1CE 4.56 W (24V DC) 13.44 W (24V DC)
FC6A-C16P4CE 4.56 W (24V DC) 13.44 W (24V DC)
FC6A-C24R1CE 3.72 W (24V DC) 16.32 W (24V DC)
FC6A-C24R4CE 3.72 W (24V DC) 16.32 W (24V DC)
FC6A-C24K1CE 4.8 W (24V DC) 16.32 W (24V DC)
FC6A-C24K4CE 4.8 W (24V DC) 16.32 W (24V DC)
FC6A-C24P1CE 4.8 W (24V DC) 16.32 W (24V DC)
FC6A-C24P4CE 4.8 W (24V DC) 16.32 W (24V DC)
FC6A-C40R1CE 4.68 W (24V DC) 21.84 W (24V DC)
FC6A-C40R4CE 4.68 W (24V DC) 21.84 W (24V DC)
FC6A-C40K1CE 4.92 W (24V DC) 21.84 W (24V DC)
FC6A-C40K4CE 4.92 W (24V DC) 21.84 W (24V DC)
FC6A-C40P1CE 4.92 W (24V DC) 21.84 W (24V DC)
FC6A-C40P4CE 4.92 W (24V DC) 21.84 W (24V DC)
FC6A-C40R1CEJ 4.92 W (24V DC) 21.84 W (24V DC)
FC6A-C40R4CEJ 4.92 W (24V DC) 21.84 W (24V DC)
FC6A-C40K1CEJ 4.2 W (24V DC) 21.84 W (24V DC)
FC6A-C40K4CEJ 4.2 W (24V DC) 21.84 W (24V DC)
FC6A-C40P1CEJ 4.2 W (24V DC) 21.84 W (24V DC)
FC6A-C40P4CEJ 4.2 W (24V DC) 21.84 W (24V DC)
Allowable Momentary Power
Interruption
10 ms or longer (when rated power supply voltage)
Withstand Voltage
Between power and FE terminals: 500V AC, 1 minute
Between input and FE terminals: 500V AC, 1 minute
Between transistor output and FE terminals: 500V AC, 1 minute
Between relay output and FE terminals: 2,300V AC, 1 minute
Between power and input terminals: 500V AC, 1 minute
Between power and transistor output terminals: 500V AC, 1 minute
Between power and relay output terminals: 2,300V AC, 1 minute
Between input and transistor output terminals: 500V AC, 1 minute
Between input and relay output terminals: 2,300V AC, 1 minute
Insulation Resistance
Between power and FE terminals: 100 MΩ or higher (500V DC insulation resistance tester)
Between input and FE terminals: 100 MΩ or higher (500V DC insulation resistance tester)
Between transistor output and FE terminals: 100 MΩ or higher (500V DC insulation resistance
tester)
Between relay output and FE terminals: 100 MΩ or higher (500V DC insulation resistance tester)
Between power and input terminals: 100 MΩ or higher (500V DC insulation resistance tester)
Between power and transistor output terminals: 100 MΩ or higher (500V DC insulation resistance
tester)
Between power and relay output terminals: 100 MΩ or higher (500V DC insulation resistance tester)
Between input and transistor output terminals: 100 MΩ or higher (500V DC insulation resistance
tester)
Between input and relay output terminals: 100 MΩ or higher (500V DC insulation resistance tester)
Inrush Current 35 A maximum
Isolation Between power terminal and internal circuit: Transformer isolated
