11: SD M EMORY C ARD
11-2 FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722
SD Memory Card Specifications
Specifications
Recommended SD Memory Card
Note: We recommend using SD memory cards that have been formatted on the FC6A Series MICROSmart.
Note: We recommend that important data is regularly backed up on separate media such as CDs or DVDs.
SD Memory Card Status
The status of the SD memory card can be checked with the SD memory card status LED [SD] and the special internal relays.
SD Memory Card Status LED [SD] and SD Memory Card Status
The SD memory card status LED [SD] turns on or flashes when the SD memory card has been recognized, while it is being
formatted, and while it is being read from or written to.
Item Specifications
Compatible SD Memory Card SD memory cards (max 2 GB), SDHC memory cards (max 32 GB)
File System
FAT16/FAT32
Note, SD memory cards are supported only when formatted as FAT16. SDHC memory cards are
supported only when formatted as FAT32. Malfunctions may occur if a different format type is used.
File Specifications
Format CSV file, ZLD file
File size 5 MB maximum (Plus CPU module 256 MB maximum)
Supported
Characters
Single-byte alphanumeric characters
The following characters cannot be used in drive names:
\ " & ( ) * + , . / : ; < > [ ] = | ^
The following characters cannot be used in file or folder names:
\ / : * ? " < >
Maximum Number of Files
Dependant on file system:
 FAT16
Subdirectory and below: Maximum 65,534
 FAT32
Subdirectory and below: Maximum 65,534
Recommended SD Memory Card SDHC memory card (32 GB maximum)
The SD memory card data may be corrupted by doing the following during access to the SD memory card.
 Turning the FC6A Series MICROSmart power OFF.
 Ejecting the SD memory card.
When ejecting the SD memory card, do so when the FC6A Series MICROSmart power has been turned off, or when the SD
memory card has been unmounted by turning on M8072.
Caution
SD Memory Card Status LED
[SD] Display
SD Memory Card Status Operation
On
 Standby status where the SD memory card can be read from or written to The SD memory card can
be ejected.
Slow flashing (1 s cycle)
 While the FC6A Series MICROSmart is recognizing the SD memory card
 The FC6A Series MICROSmart is unmounting the SD memory card because
unmount SD memory card (M8072) was turned on
Do not eject the SD
memory card.
Quick flashing (100 ms cycle)  Reading or writing the SD memory card
Off
 The SD memory card is not inserted
 An unsupported or unformatted SD memory card was inserted
 Unmount SD memory card (M8072) is on, so the SD memory card has
been unmounted
 The FC6A Series MICROSmart power is off
If the SD memory card is
inserted, it can be
ejected.
