IDEC MICROSmart FC6A Series User Manual

11: SD M EMORY C ARD
11-28 FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722
Example 1: When all of the data in the CPU module matches the ZLD file
The download is not executed.
Download CPU Module Data
Data Stored in the ZLD File on
the SD Memory Card
CPU Module Data
after Download
CPU Module
System Software
Ver1.23 Ver1.23 Ver1.23
User program Project1 Project1 Project1
Program comments Comment1 Comment1 Comment1
Example 2: When the system software versions are different
Only the system software will be downloaded.
Download CPU Module Data
Data Stored in the ZLD File on
the SD Memory Card
CPU Module Data
after Download
CPU Module
System Software
Ver1.23 Ver1.30 Ver1.30
User program Project1 Project1 Project1
Program comments Comment1 Comment1 Comment1
Example 3: When the user program and program comments are different
The user program and program comments will be downloaded.
Download CPU Module Data
Data Stored in the ZLD File on
the SD Memory Card
CPU Module Data
after Download
CPU Module
System Software
Ver1.30 Ver1.30 Ver1.30
User program Project1 Project2 Project2
Program comments Comment1 Comment2 Comment2
