IDEC MICROSmart FC6A Series User Manual

2: P RODUCT S PECIFICATIONS
2-34 FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722
Terminal Arrangement and Wiring Examples
■ AC Power Type
Applicable connector
(2) Sensor power terminals, input terminals
DC Sink Input Wiring
DC Source Input Wiring
(3) Output terminals
Relay Output
16-I/O Type: Screw fastened type: FC6A-C16R1AE
Push-in type: FC6A-C16R4AE
(1) Power supply terminals
Screw fastened type FC6A-PMTD03PN02
Push-in type (AC) FC6A-PMSDA03PN02
(2) Sensor power terminals, input terminals
Screw fastened type FC6A-PMTA12PN02
Push-in type FC6A-PMSA12PN02
(3) Output terminals
Screw fastened type FC6A-PMTA09PN02
Push-in type FC6A-PMSA09PN02
Screw fastened type Push-in type (1) Power supply terminals
(2)
(3)
(1)
(2)
(3)
(1)
AC Power Input
L N PE
: Fuse
: Load
L
+24V 0V COM I0 I1 I2 I3 I4 I5 I6 I7 I10
Power Output
24V DC Input
-
+
2-wire
Sensor
+24V
0V
Power Output
COM
I0 I1 I2 I3 I4 I5
I6
I7 I10
24V DC Input
+
-
2-wire
Sensor
Relay Output
Q0
Q1 Q2 Q3 COM1COM0 Q4 Q5 Q6
-
+
LLLL
