2: P RODUCT S PECIFICATIONS
2-44 FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722
(3) Output terminals
Relay Output: FC6A-C16R1DE, FC6A-C16R4DE
Transistor Sink Output: FC6A-C16K1DE, FC6A-C16K4DE
Transistor Protection Source Output: FC6A-C16P1DE, FC6A-C16P4DE
Relay Output
Q0
Q1 Q2 Q3 COM1COM0 Q4 Q5 Q6
-
+
LLLL
Transistor Sink Output (12 V)
Q1
Q2 Q3 Q4 Q5Q0 Q6 COM0(-) V0(+)
L L L L LLL
+
-
Transistor Protection Source Output (12 V)
Q1
Q2 Q3 Q4 Q5Q0 Q6 COM0(+) V0(-)
L L L L LLL
-
+
