Installation Procedures – Auger Calibration
Install the Sensors
• Install the Triangle Holder on the tilting, but not rotating part of the
auger as shown in this picture.
• The Triangle Holder may be setup in ANY position or orientation.
• If there is no space available for the Triangle Holder, it is possible to
install the 2 Mini Sensors without it. Follow the same rules and
procedures described in the Tilt Bucket Calibration section of this
manual.
54
