52
4.3. Card Printer Test
Basically Card Printer use standard printer device so you can be used same as general paper
printer. In the case of magnetic stripe, contact, contactless encoder option, you will need to
install appropriate driver and operate individually. Encoding operation will be controlled by
“CARD PRINTER SDK”. You can test all feature of printer by Card printer Test. Card Printer
Test program is developed by using “SMART Printer SDK”
(1) CardPrinterTest
When CardPrinterTest is run, all function can be tested individually.
Figure 78 CardPrinterTest
① Select Printer: select printer to test. In the picture, “IDP SMART-31 Card Printer” is the
Printer name, SMART1 is the Printer ID, and USB005 is the connected port.
② Control : To execute each step to test
