13
IDS LCD Keypad User Manual 700-292-01C Issued March 2009
5.3 Medical Alarms
[M]
(Hold down the [M] key for two seconds until the keypad buzzer sounds)
If the [M] key is pressed until the keypad beeps (approximately 2 seconds) a MEDICAL ALARM
condition will be activated.
The keypad buzzer will beep 5 times.
A medical reporting code will be reported to the monitoring company.
5.4 Duress Alarms
[#] + [DURESS CODE]
This is a special user code that should only be used in the unique situation where an intruder
forces one to disarm the system “under duress”.
When a [DURESS CODE] is entered, the control panel disarms. A Duress Alarm Code (if
programmed) will be reported to the monitoring company.
It is advisable to choose a Duress code which can be easily remembered by all family (or staff)
members.
6. Alarm Memory
The Alarm Memory displays any zones which were tampered, violated, or bypassed during the last arm
cycle. A flashing ARM indicator notifies the user of an Alarm Memory condition. To view the Alarm
Memory, disarm the panel and continue as follows:
[0]
(Hold down the [0] key for two seconds until the keypad buzzer sounds)
1. Hold down [0] until the keypad buzzer sounds.
2. The ARM and POWER indicators will turn off and the keypad buzzer will sound briefly.
3. Use the [MED] or [PANIC] keys to scroll through the zones violated during the last armed
period.
4. Press 2 to display zones which were bypassed.
5. Press 3 to display which zones were tampered.
6. Press 1 to return to violated zones.
7. The Alarm Memory is erased at the beginning of each arm cycle.
7. Zone Options
7.1 Changing a Zone Name
Table 1 : Alarm Panel Zones
