16
IDS LCD Keypad User Manual 700-292-01C Issued March 2009
IDS 1632 & IDS 1224 Panels
The first menu option - Menu Option 0 - 'Add User' is displayed by default.
6. Select a programmable option from Table 1. In the case of the IDS 1632 and IDS 1224, one may
use the [PANIC] or [MED] keys to scroll through the menu options.
7. Confirm the entry by pressing the [*] key. A valid entry is confirmed by a long beep. An invalid
entry will be signalled by means of an error beep (3 short beeps). If an error beep occurs, press
the [#] key to clear all previous entries, and repeat steps 2 – 6
Example:
To add a new user code, enter User Program Mode by completing steps 2 - 5 as listed above. In the
case of the IDS 816 when prompted to enter a 'Menu Option', enter a value of [0] (See table 1) followed
by [*]. In the case of the IDS 1632 and the IDS 1224, Menu Option 0 will be displayed on the LCD screen
by default. Press the [*] to confirm your entry. For all panels, once prompted to 'Enter a User Code', input
a [NEW USER CODE] followed by the [*] key. Once the user code is programmed, enter the next code
followed by [*]. To exit the program mode press the [#] key.
For a full list of options, refer to Table 2. Programming of these options is explained below.
8.3 Explanation of Programmable Options
8.3.1 Option 0 - Add a New User Code
Hold [*] + [Master Code] + [*] + [0] + [*] + [New Code] + [*]
1. Enter the User Program Mode as per steps 1 - 4 of (8.2).
2. IDS 816 Panel
When prompted for the 'Menu Option' press the [0] key followed by the [*] key to select
programmable option 0.
IDS 1632 & IDS 1224 Panels
Menu option 0 - 'Add User' is displayed on the LCD Screen by default. As this is the
programmable option you require, press the [*] key to confirm your entry.
3. The ARM key flashes and the LCD prompt reads 'Enter User Code'.
4. Enter the [NEW USER CODE] followed by the [*] key to confirm the entry. A valid entry is
confirmed by a long beep. An invalid entry will be signalled by means of an error beep (3 short
beeps). If an error beep occurs, press the [#] key to clear all previous entries and repeat steps
1 - 4.
5. Further codes can be added by repeating step 4 above. When a user code is added, it is stored
in the first available user slot.
6. Press the [#] key to exit the User Program Mode.
8.3.2 Option 1 - Edit a User Name
Hold [*] + [Master Code] + [*] + [1] + [*] + [User Code] + [*]
1. Enter the User Program Mode as per steps 1 - 4 of (8.2).
2. IDS 816 Panel
When prompted for the 'Menu Option' press the [1] key followed by the [*] key to select
programmable option 1.
IDS 1632 & IDS 1224 Panels
Menu option 0 - 'Add User' is displayed on the LCD Screen by default. To select menu option 1 -
'Edit Name', press the [1] key followed by the [*] key or alternatively use the [PANIC] or [MED]
keys to scroll through the list of programmable options until you reach Menu Option 1 and press
the [*] key to confirm your selection.
