p.59F5 SETUP MENU
5 F5 SETUP MENU
Table 12-1 Default Output Settings for Input Source
OUTPUT Door Relay
(DR)
Alarm Relay
(AR)
TTL#1
(T1)
TTL#2
(T2)
Buzzer
(BZ)
[1] EXIT BUTTON 03 00 00 00 00
[2] DOOR CONTACT 00 99 00 00 00
[3] AUX Input #1 00 00 00 00 00
[4] AUX Input #2 00 00 00 00 00
[5] TAMPER ALARM 00 99 99 99 99
