3) Rear View
• Electronics cover (1) with the following elements on the rear
panel of the electronics compartment:
AC line power connector (2)
AC power switch (3)
Data I/O, 25-contact female connector (4)
• Media insertion slot (5) made up of two adjustable paper guides
• Printhead lever (6).
• Printer identification plate located underneath the printer.
Fig. 9
5
1
3
5
2
6
4
