5) Loading Fanfold Media
Fanfold media loading can be performed in the following two ways:
a) Preliminary Steps:
• Install a box of fanfold media (3) at the rear of the printer. The
box must be placed parallel to the printer. Orient the box so
that the media, when inserted into the printer, has its heat-
sensitive side facing up.
• Switch on the printer (see Page 14).
b) Automatic Media Loading:
• Insert the leading document (1) of the stock into the insertion
slot (2). It will be drawn in automatically.
• The document is automatically ejected after some possible
back and forth movements, which correspond to the
separation mark self-calibration phase.
c) Manual Media Loading (Requires Lifting of the Printhead):
• Push the printhead lever (4) up.
• Insert the leading document (1) of the stock into the insertion
slot (2). Push it in until it protrudes from the ejection slot.
• Lower the printhead lever (4). The document is automatically
ejected, after some possible back and forth movements,
which correspond to the separation mark self-calibration
phase.
IMPORTANT:
Should media insertion into the rear feed slot be difficult,
p
erform the paper path ad
j
ustment a
g
ain
(
see Pa
g
e 16). Also
check that the media stock (box (3)) is correctly aligned with
the paper path. If media feeds unevenl
y
, move the bo
x
further awa
y
from the insertion slot.
