C DESCRIPTION
1) Physical Characteristics
Overall printer dimensions, cover open, without roll media shaft:
• Depth (A) 300 mm (11.8 in)
• Height (cover open) (B) 368 mm (14.5 in) approx.
• Width (cover open) (C) 300 mm (11.8 in) approx.
Fig. 6
A
C
B
C
