8
Overall printer dimensions with the covers closed and the media
shaft installed:
• Depth (A) 500 mm (19.69 in)
• Height (B) 226 mm (8.9 in) (feet included)
• Width (C) 200 mm (7.87 in)
Weight:
• Without any options 7 kg (15.4 lbs.), approx.
• All options included <8 kg (<17.6 lbs.)
Operating temperature:
• +5°C (41°F) to +40°C (104°F)
Relative humidity, consumables excluded:
• 20% to 80%, non-condensing
Fig. 7
A
C
B
