IFM Electronic Efector 300 - Page 11

11
UK
F
2 x D
S
3
F
S
5 x D
2
S = disturbance; D = pipe diameter; F = flow direction
► Install in front of or in a rising pipe:
F
F
4
F
5
F = flow direction
With empty pipe detection:
► Install the unit according to figure 1, 4 or 5�
