21
UK
Explanation min/max memory (MEM)
HI�F Max� value flow
LO�F Min� value flow
HI�T Max� value temperature
LO�T Min� value temperature
Explanation empty pipe (EPD)
EP�On Empty pipe detection on / off
dEP�E� Delay time empty signal
dEP�F Delay time full signal
EP�Pr Current measured value of empty pipe detection
EP�SP Switch point of empty pipe detection
8.5
Explanation simulation (SIM)
S�FLW Simulation flow value
S�TMP Simulation temperature value
S�Tim Simulation time
S�On Simulation start
9 Set-up
After power on and expiry of the power-on delay time (approx� 5 seconds) the unit
is in the normal operating mode� It carries out its measurement and evaluation
functions and generates output signals according to the set parameters�
For the analogue output 2 (OUT2), the output signal is 20 mA during the power-on
delay time�
In the first 2 seconds, analogue output 1 (OUT1) is passive and available for IO-
Link communication� During the remaining power-on delay time, the output signal
is at 20 mA�
