10.3.3 Table repeatability and accuracy
Values for sampling rate 15 Hz
Distance
in [mm]
Repeatability Accuracy
white
90 % remission
grey
18 % remission
white
90 % remission
grey
18 % remission
300���1000 ± 11,0 mm ± 13,0 mm ± 31,0 mm ± 33,0 mm
1000���2000 ± 28,0 mm ± 30,0 mm ± 48,0 mm ± 50,0 mm
2000���3000 ± 50,0 mm ± 50,0 mm ± 70,0 mm ± 70,0 mm
3000���4000 ± 85,0 mm ± 85,0 mm ± 105,0 mm ± 105,0 mm
4000���5000 ± 105,0 mm — ± 125,0 mm —
5000���6000 ± 145,0 mm — ± 165,0 mm
Values for sampling rate 1 Hz
Distance
in [mm]
Repeatability Accuracy
white
90 % remission
grey
18 % remission
white
90 % remission
grey
18 % remission
300���1000 ± 8,0 mm ± 10,0 mm ± 28,0 mm ± 30,0 mm
1000���2000 ± 25,0 mm ± 25,0 mm ± 45,0 mm ± 45,0 mm
2000���3000 ± 38,0 mm ± 38,0 mm ± 58,0 mm ± 58,0 mm
3000���4000 ± 70,0 mm ± 70,0 mm ± 90,0 mm ± 90,0 mm
4000���5000 ± 100,0 mm — ± 120,0 mm —
5000���6000 ± 100,0 mm — ± 120,0 mm
*Range referred to black (6 % remission) ≤ 4000 mm.
The values apply at:
• constant ambient conditions (23°C / 960 hPa)
• only after unit powered up for 10 minutes
• Extraneous light on the object max�: 100 klx
