8.2.1 Explanation main menu
SP1 Maximum limit value for the set process value
rP1 Minimum limit value for the set process value
ImPS Pulse value
ImPR Pulse reset
FEP Frequency output of the end point of the flow value
FrEP Frequency output of the end point of the frequency
OU1 Output function for OUT1 (volumetric flow or consumed quantity)
OU2
Output function for OUT2 (volumetric flow or temperature)
As an alternative: configure OUT2 (Pin2) as input for external reset signal:
Setting: [OU2] = [In�D]
Hno Hysteresis normally open
Hnc Hysteresis normally closed
Fno Window normally open
Fnc Window normally closed
ImP Pulse output
FRQ Frequency output
dOU Diagnostic output
I Current output
U Voltage output
In�D External input
ASP2 Analogue start value for the set process value
AEP2 Analogue end value for the set process value
SP2 Maximum limit value for the set process value
rP2 Minimum limit value for the set process value
D�In2 Configuration of the input (Pin2) for counter reset
EF Extended functions / opening of menu level 2
