8.3.1 Explanation extended functions (EF)
rES Restore the factory setting
rTo Counter reset: manual reset / time-controlled reset
CFG Submenu basic settings
MEM Submenu min/max memory
EPD Submenu empty pipe
SIM Submenu simulation
8.3.2 Submenu basic settings (CFG)
FOU1 Behaviour of output 1 in case of an error
FOU2 Behaviour of output 2 in case of an error
dST Start-up delay of volumetric flow monitoring
P-n Output logic: pnp / npn
dAP Measured value damping / damping constant in seconds
diS Update rate and orientation of the display
Uni
Standard unit of measurement for volumetric flow: litres/minute or cubic
metres/hour
SELd
Standard measuring unit of the display: volumetric flow value / medium
temperature / meter reading
SEL2 Standard unit of measurement for evaluation via OUT2
LFC Low flow cut-off
FPro Totaliser: behaviour with negative flow
Fdir Direction of flow
