Ihse 474 Series User Manual

Description
2014-04-15 11
3.3 Product Range
3.3.1 Part Numbers
Part numbers for Connections via Cat X or Fiber Cable
All devices are available in the following versions:
 Connection via Cat X cable (x = "C")
 Connection via Single-mode fiber cable (x = "S")
 High speed connection (3.125 Gbit/s) via Single-mode fiber cable
(x = "X")
Fiber devices can be used with Multi-mode and Single-mode cables (see
Chapter 7.2.2, Page 64).
Part numbers for CPU Unit and CON Unit
The part numbers for the CPU Unit and the CON Unit can be derived from
the part number of the complete device.
 CPU Unit: L474
 CON Unit: R474
All devices in the K474 series are technically compatible with devices in
the K477 series.
3.3.2 Chassis
Model Description
474-BODY2
Empty chassis for up to 2 boards, 1x external power
supply unit
474-BODY2R
Empty chassis for up to 2 boards, 1x external power
supply unit, preparation for redundancy for a second
power supply unit (external)
474-BODY2N
Empty chassis for up to 2 boards, 1x internal power
supply unit, preparation for redundancy for a second
power supply unit (external)
474-BODY4
Empty chassis for up to 4 boards, 1x external power
supply unit
474-BODY4R
Empty chassis for up to 4 boards, 1x external power
supply unit, preparation for redundancy for a second
power supply unit (external)
