MDtest (100-140 V) - User’s Manual 2 Description of the instrument
2.9 Abbreviations
L phase conductor
N neutral conductor
PE protect earth conductor
ALT alternative (substitute) method
DIF differential method
DIR direct method
60601Earth protect conductor current – direct method (EN 60601-1)
60601Touch touch current – direct method (EN 60601-1)
60601Pat patient leakage current – direct method (EN 60601-1)
60601MAP patient leakage current Mains on applied part – direct method
(EN 60601-1)
Eq equipment
R L-N reversal
Ext external
Touch touch
Pat patient
B battery
M mains part
CP conductive part
AP applied part
MD measuring device
FE functional earth
Mains mains voltage supply
DUT device under test
DUT PE device under test protective earth
Open PE open protective earth
Open N open neutral
socket
connection: Test Socket 1
RPE
connection: terminal RPE (Note: also applies to the other
terminals)
c
2018 ILLKO, s.r.o. www.illko.cz Page 14
