MDtest (100-140 V) - User’s Manual 1 Introduction
WARNING
• It is necessary to respect all safety regulations applicable to the
particular measurement.
• Test Socket 1 of the MDtest must not be used for continuously
powering the appliance. It is intended for test purposes only;
max. test duration is 25 min @ ≤12 A and 60 s @ 12÷16 A.
• The functional test may only be performed after the DUT has
successfully passed the safety test.
• Dangerous voltage or mains voltage may be present on Test
Socket 1 during some tests.
• Devices under test which are connected to Test Socket 1 of the
MDtest can be powered by mains voltage during some tests. The
appliance can thus be activated.
• The PE terminal is connected to the PE terminal of Test Socket
1. When using the MDtest, do not connect any voltage to the
terminal PE. If connected, there is a danger of electric shock or
damage to the MDtest.
• Use only standard or optional accessories supplied with the
MDtest by your distributor.
The figures in this manual are only illustrative and may vary slightly
from the actual state or the version on your instrument.
1.2 Performance MDtest
The MDtest is a professional, compact, portable analyzer, designed to verify the
electrical safety of medical devices. The MDtest has an extraordinary wide scope
of use thanks to a lot of optional accessories, which enable testing practically any
portable or hard-wired, one-phase or three-phase medical device.
1.3 Applied standards
• EMC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . EN 55011:2009+A1:2010
EN 61326-1:2013
EN 61000-4-2:2009
EN 61000-4-3:2006+A1:2007+A2:2010
EN 61000-4-4:2004+A1:2010
EN 61000-4-5:2006
EN 61000-4-6:2009
EN 61000-4-11:2004
• LVD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . EN 61010:2010
EN 61010-2-030:2010
EN 61557-16:2014
EN 62353:2014
c
2018 ILLKO, s.r.o. www.illko.cz Page 6
