MDtest (100-140 V) - User’s Manual 6 Instrument main menu
6.2.4 Menu - Measurement result
In this menu it is possible to set the result of measurement operation: Failed /
Passed / N/A (not performed).
The default setting for the visual inspection, functional test and mea-
suring results is PASSED.
6.3 Menu - Test sequences
In this menu you can view a list of available measurement test sequences which can
be assigned to the currently selected appliance.
Assigning the test sequences from the list of the currently selected appliance is done
as follows:
• Press the [menu] key.
• Select the Test sequences item and press the [ent] key for confirmation.
• Select required test sequence.
• Press the [ent] key to check each individual step in the test sequence.
• Press the [Load] key to assign the test sequence to DUT.
The list of test sequences cannot be modified in MDtest – it is trans-
ferred from the PC software.
6.4 Menu - Empty file
In this menu the temporary memory is erased, i.e.:
• the ID number is empty
• all measured values are deleted
• the results of the visual inspection, functional test and measurement operation
are set to PASSED
• the test sequence is deactivated
6.5 Menu - Setup
6.5.1 Menu - System info
These items can be displayed Serial number, Firmware version, Production date and
The number of records.
6.5.2 Menu - Measure DC values
This will activate the measurement and display DC components in the selected
leakage currents:
c
2018 ILLKO, s.r.o. www.illko.cz Page 53
