MDtest (100-140 V) - User’s Manual 6 Instrument main menu
6 Instrument main menu
6.1 Main menu structure
• DUT properties
– Measured values
– Visual inspection result
– Functional test result
– Measurement result
• Test sequences
• Empty file
• Setup
– System info
– Measure DC values
– Self-test
– Date – next calibration
– Erase database
– Measurement locking
– Save last method
– Date and Time
– Keys beep
– Volume
– Language
The operating the menu is as follows:
• Press the [menu] key to open the Main menu.
• Use the [N] or [H] keys to select the desired function, confirm the selection by
pressing the [enter] key.
• Use the [esc] keys to return.
6.2 Menu - DUT properties
6.2.1 Menu - Measured values
This menu can be used to display measured values with an evaluation status. All
data are transferred from the temporary memory.
6.2.2 Menu - Visual inspection result
In this menu it is possible to set the result of visual inspection: Failed / Passed /
N/A (not performed).
6.2.3 Menu - Functional test result
In this menu it is possible to set the result of functional test result: Failed / Passed
/ N/A (not performed).
