MDtest (100-140 V) - User’s Manual 5 Database operations
5 Database operations
5.1 Storing measurement data
A set of data can be stored for each appliance. Data can be created and transferred
to the MDtest from a PC and other data is created during the measurement. Each
set of data (file) has its unique identification number (ID) assigned.
The structure of the file:
Item Transfer from PC Description Created
ID yes 1-20 ASCII
code charts
barcode scanner,
ID editor
test sequence yes sequence
of test steps
transfer from PC,
assign of the test sequence
measurement
data
no measurement and store
of the value
final
evaluation
no initial evaluation (passed) is
possible to change manually
date of
measurement
no editable on
a PC only
saving the measured value
5.2 The structure of the data memory
Measured values and other possible data are stored as a file in a temporary memory
where the ID is assigned and finally the file is transferred to the main memory.
Conversely you can load a set of measurements of a particular appliance from the
main memory to the temporary memory and then edit it.
Measuring up to 4 000 DUTs can be stored in the main memory.
To perform the whole procedure:
• Read the device ID number (use the barcode scanner) or enter the ID from
the keyboard.
• Perform all required measurements.
• Check the visual inspection, functional test and measured values (PASSED
is preset by default).
• Press the [save] key, the data will be transferred from the temporary memory
to main memory.
c
2018 ILLKO, s.r.o. www.illko.cz Page 45
