MDtest (100-140 V) - User’s Manual 4 Measurements
Procedure:
• Press the [7 IDIF] key and release it.
• If the measurement with open PE can be performed, press the [OpenPE] key.
• Press the [Eq] or [OpenPE] keys repetitively in order to measure with L-N
reversal. Symbol L-N reversed is displayed.
• Connect the tested appliance: plug in its mains plug into Test Socket 1 and
plug the applied part into the PAT terminal. If necessary (e.g. protective
class II appliances), plug the test lead into the PE terminal (if Open PE is
selected plug into the PAT terminal).
• Press the [TEST] key.
• Switch on the tested appliance’s mains switch.
• Press the test tip against the exposed conductive part of the tested appliance.
• The HOLD function can be used (press the [H] key).
• Switch off the tested appliance’s mains switch.
• Finish the measurement (see chapter 4.2.1).
