MDtest (100-140 V) - User’s Manual 7 Additional informations
HOLD function
By pressing and releasing the [H] key, the last measured value is displayed even if
the measurement has either ended or is in progress. The HOLD function can be
cancelled (measurement is still in progress) by pressing and releasing the [H] key.
Figure 41: HOLD function
Test sequence
After activation, the test sequence symbol is displayed (Figure 42).
Figure 42: Test sequence
Measured value is out of range
If the value is higher / lower then max. / min. range, the maximal / minimal
value is displayed with the symbol > "higher then" (Figure 43) or < "lower then"
(Figure 44).
Figure 43: Measured value is out of range (max)
Figure 44: Measured value is out of range (min)
c
2018 ILLKO, s.r.o. www.illko.cz Page 63
