Chapter 1: Introduction
RTMS Echo User Guide ©2019 Image Sensing Systems Inc. 1-2
RTMS Echo Technical Specifications
*RTMS Echo meets the requirements of the minimum sweep rate as specified
by ERC recommendation (70-03) as specified in IR2030/12/9 2014/88/UK
June 2014.
Table 1-1: Radar Frequency - Radar
Country
Bottom
Frequency
Top
Frequency
Power
USA/RUS 24.075 GHZ 24.175 GHZ 20 dBm max
FR/Other Europe 24.145 GHZ 24.245 GHZ 20 dBm max
UK* 24.145 GHZ 24.245 GHZ 20 dBm max
Table 1-2: Wi-Fi Frequencies
Country Channels
Bottom
Frequency
Top
Frequency
Power
North America 1 - 11 2412 MHZ 2462 MHZ 20 dBm max
Europe 1 - 13 2412 MHZ 2472 MHZ 20 dBm max
Table 1-3: Specifications
Measurement Dimensions
Mechanical Width: 12.5 in. (32 cm)
Height: 7.25 in. (19 cm)
Depth: 2.5 in. (7 cm)
Weight: 4.5 lbs (1.5 kg) with bracket
Electrical Voltage: 12-24 V DC
Power: Max = 7.9 Watts; Avg = 7.3 Watts
Temperature Range -40 to +165°F (-40 to 74C°)
Humidity Up to 95% Relative Humidity
Ingress Protection IP67
(Table continues on the next page.)
