6.10.8 Technical Specs - WiFi (WLAN)
2.4 GHz (Draft-g)
Parameter
Value
Remarks
Standards
IEEE 802.11abg
Certification
WiFi certified (WMM)
Data rate
54 Mbps
11 Mbps
IEEE 802.11g
IEEE 802.11b
Operating frequency
2.412 GHz ... 2.462 GHz
channel 1...11, 5 MHz separation
IEEE 802.11 abg ISM Band
Network type
Ad-Hoc, managed
RF output power
+20 dBm
+17 dBm
+15 dBm
IEEE 802.11b (CCK)
IEEE 802.11g (OFDM)
IEEE 802.11a (OFDM)
Receiver sensitivity
-73 dBm
-86 dBm
IEEE 802.11g (54 Mbps)
IEEE 802.11b (11 Mbps)
Encryption
WEP to 104 Bit
WPA-PSK TKIP/RC4
WPA2-PSK CCMP/AES
open system
(8 to 63 characters)
1
(8 to 63 characters)
1
Modulation
DSSS (DBPSK, DQPSK, CCK)
OFDM (BPSK, QPSK, 16-QAM, 64-QAM)
IEEE 802.11b
IEEE 802.11ag
Operating temperature range
-30°C to +85°C
operating (ET version)
Power consumption
1.5 W
Antenna - ACC/WLAN-ANT-RP-SMA
Parameter
Value
Remarks
Type
clip on antenna
Connector
RP-SMA (female)
reverse-SMA, antenna side: female
Flexibility
flexible joint
bend and rotate
degrees of freedom for positioning
Operating frequency
single band / dual band
2.4 GHz / 5 GHz
Antenna gain
1.5 dBi, 2.1 dBi
2.4 GHz / 5 GHz
Impedance
50 Ω
Operating temperature range
-20°C to +65°C
Mechanical dimensions
L: 108 mm / 82.5 mm
diameter: 7.8 mm / 10 mm
with / without flexible joint
diameter: antenna / SMA
Antenna - ACC/WLAN-MAG-ANT-RP-SMA
Parameter
Value
Remarks
Type
magnetic base antenna
with 1.5 m cable
Connector
RP-SMA (female)
with 1.5 m low loss cable
reverse-SMA, antenna side: female
Flexibility
magnetic attachment
Operating frequency
single band 2.4 GHz
Antenna gain
5 dBi
2.4 GHz
Voltage standing wave ratio
<1.6 : 1
characterizes cable transmission loss
