6.10.7 SUPPLY Sensor supply module
Parameter
Value (typ./ max.)
Remarks
Configuration options
5 adjustable ranges
The sensor supply module always got 5
selectable voltage ranges.
Default ranges: +5 V to +24 V
Output voltage
Voltage
(+2.5 V)
+5.0 V
+10 V
+12 V
+15 V
+24 V
( ± 15 V)
Current
580 mA
580 mA
300 mA
250 mA
200 mA
120 mA
190 mA
Netpower
1.5 W
2.9 W
3.0 W
3.0 W
3.0 W
2.9 W
3.0 W
special order, +12 V can be replaced by +2,5 V
set globally for all channels of an amplifier.
special order, +15 V can be replaced by ± 15 V
Isolation
Standard:
option, upon request:
non isolated
isolated
output to case (CHASSIS)
nominal rating: 50 V, Test voltage (10 sec.): 300
V, not available with option ±15 V.
Short-circuit protection
unlimited duration
to output voltage reference ground
Accuracy of output voltage
<0.25% (typ.)
<0.5% (max.)
<0.9% (max ).
at terminals, no load
25°C
25°C
over entire temperature range
Efficiency
typ. 72%
typ. 66%
typ. 55%
typ. 50%
10 V to 24 V none isolated
5 V
10 V to 24 V isolated
5 V
Max. capacitive load
>4000 µF
>1000 µF
>300 µF
2.5 V to 10 V
12 V, 15 V
24 V
