Immergas VICTRIX OMNIA - Immergas Flue Systems

24
INSTALLER
USERMAINTENANCE TECHNICIAN
TECHNICAL DATA
1.15 INTERNAL INSTALLATION USING A
RECESSED FRAME WITH DIRECT AIR
INTAKE
Conguration type B, open chamber and fan assisted
Using a kit separator one can achieve direct air intake (Fig. 17)
and ue gas exhaust in a single chimney or directly outside.
In this conguration the boiler is classied as type B
23
.
With this conguration:
- air intake takes place directly from the environment in which
the appliance is installed (the recessed frame is ventilated), and
only functions in permanently ventilated rooms;
- the ue gas exhaust must be connected to its own individual
chimney and channelled directly into the external atmosphere.
e technical regulations in force must be respected.
Separator kit installation (Fig.16).
1. Install the discharge ange on the central hole of the boiler,
positioning the relative gasket with the circular projections
downwards in contact with the boiler ange, and tighten using
the hex screws with at tip contained in the kit.
2. Remove the at ange present in the lateral hole with respect
to the central one (according to needs) and replace it with the
intake ange, positioning its gasket already present in the boil-
er and tighten using the supplied self-threading screws.
3. Fit the bends with male side (smooth) in the female side of the
anges (the intake bend should face the rear side of the boiler).
4. Fit the exhaust pipe with the male side (smooth) to the female
side of the bend up to the end stop, making sure that the inter-
nal wall sealing plate has been tted and connecting the re-
quired ue according to personal requirements.
Max. length of exhaust duct.
e ue pipe (both vertical or horizontal) can be extended to a
max. length of 36 linear metres.
16
17
