Immergas VICTRIX OMNIA - Outdoor Installation in Partially Protected Area

28
INSTALLER
USERMAINTENANCE TECHNICIAN
TECHNICAL DATA
Extensions for Ø 80/125 vertical kit (Fig. 25)
e kit with this conguration can be extended to a max. straight
vertical length of 32 m, including the terminal. If additional com-
ponents are assembled, the length equivalent to the maximum al-
lowed must be subtracted. In this case the special extensions must
be requested.
C
33
25
1.18 SEPARATOR KIT INSTALLATION
Type C conguration, sealed chamber and fan assisted,
separator kit Ø 80/80
is kit allows air to come in from outside the building and the
exhaust to exit from the chimney, ue or intubated duct through
divided ue exhaust and air intake pipes.
Combustion products are expelled from pipe (S) (in plastic, so as
to resist acid condensate).
Air is taken in through duct (A) for combustion (this is also in
plastic).
e intake pipe (A) can be installed either on the right or le hand
side of the central exhaust pipe (S).
Both ducts can be routed in any direction.
Mounting the separator kit Ø80/80 (Fig.26):
1. Install the concentric ange (2) on the central hole of the boil-
er, positioning gasket (1) with the circular projections down-
wards in contact with the boiler ange.
2. Tighten with the hexagonal head and at point screws provid-
ed in the kit.
3. Replace the at ange present in the lateral hole with respect to
the central one (according to needs) with the ange (3), posi-
tioning the gasket (2) already present in the boiler
4. Tighten with the supplied self-tapping screws with drill bit.
5. Fit the bends with male side (smooth) (5) in the female side of
the anges (3 and 4).
6. Fit the intake terminal (6) with the male side (smooth) in the
female side of the bend (5) up to the end stop, ensuring that the
internal and external wall sealing plates are tted
7. Fit the exhaust pipe (9) with the male end (smooth) to the fe-
male end of the bend (5) up to the end stop; making sure that
the internal wall sealing plate has been tted, this will ensure
sealing and joining of the elements making up the kit.
C
53
* - C
83
1
4
7
9
5
5
6
7
8
3
2
S
A
26
e kit includes (Fig. 26):
No.1 Exhaust gasket (1)
No.1 Flange gasket (2)
No.1 Female intake ange (3)
No.1 Female exhaust ange (4)
No.2 Bend 90° Ø 80 (5)
No.1 Intake terminal Ø 80 (6)
No.2 Internal wall sealing plates (7)
No.1 External wall sealing plate (8)
No.1 Exhaust pipe Ø 80 (9)
* to complete C53 conguration, also provide for a
“green range” roof discharge terminal.
e conguration on walls opposite the building is not allowed.
Installation clearances (Fig. 27)
e minimum installation clearance measurements of the Ø
80/80 separator terminal kit have been stated in some limit condi-
tions.
C
43
27
