37
5.3.2.2 Replacing the pressure reducer DM2 for the bracing bubble
Unwind the hose package from the reel. Pull the transparent and the blue hose off the
pressure reducer 2 (DM2). For this purpose press the black circlip on the pressure reducer
and pull on the hose at the same time. Loosen the switch panel nut with the pliers and
unscrew.
Unscrew elbow-type screwed sockets. Replace the pressure reducer and mark it with DM2.
Screw in both angular fittings with O-rings.
Insert the pressure reducer into the hose reel and screw on the switch panel nut. Put 6 mm
hoses back in place. Attention: Note direction of flow (arrow on pressure reducer)! Verify
pressure and adjust, if necessary. (In this respect refer to point 4.4.2 )
